Loading rolls in the Roll 1 (Upper) holder
1
Press the Load button.
2
Press ▲ or ▼ to select Roll 1 (Upper), and then press the OK button.
Note
•
If any cut sheet has been fed, or roll paper that will not be used has been fed from Roll 1 (Upper), a
message is shown requesting you to remove it.
Press ▲ or ▼ to select Yes, and then press the OK button. Remove the paper and go to the next step.
•
If roll paper is loaded in Roll 1 (Upper) but Roll 1 (Upper) is not selected as the paper source, a message
asking you whether or not to change paper is displayed.
Press ▲ or ▼ to select Load, and then press the OK button. Remove the paper and proceed to the next
step.
3
Open the Top Cover and lift the Ejection Guide.
4
Holding the Roll Holder so that the side with the white
gear faces the side of the Roll Holder Slot with a
white gear, load the Roll Holder shaft (a) into the
grooves (b) on both ends of the Roll Holder Slot.
Loading Rolls in the Printer
iPF840 Series
Basic Guide
Handling Paper Handling rolls
16
