Important
•
Do not touch the Linear Scale (a), Carriage
Shaft (b), or Ink Tube Stabilizer (c). Touching
these parts may damage them.
3
If the ventilation duct (a) is dirty, use a damp cloth that
you have wrung out completely to wipe it clean. Move
the Carriage out of the way manually if the Carriage is
concealing the ventilation duct, and then clean the
duct.
4
Pull the Printhead Fixer Lever forward all the way to open
it completely.
5
Pull up the Printhead Fixer Cover to open it completely.
Replacing the Printhead
iPF840 Series
Basic Guide
Consumables and Maintenance Printheads
42
