f
Paper Feed Slot
When loading a roll, insert the edge of the roll paper here. You can load rolls in two positions, on the printer
side in the Roll 1 (Upper) position and on the roll unit side in the Roll 2 (Lower) position.
g
Holder Stopper
Secure rolls on the Roll Holder with this part.
h
Ink Tank Cover
Open this cover to replace an Ink Tank. (See "Ink Tank Cover (Inside).") ➔P.72
i
Control Panel
Use this panel to operate the printer and check the printer status. (See "Control Panel.") ➔P.55
j
Release Lever
Releases the Paper Retainer. Lift this lever toward the front of the printer when loading paper.
k
Maintenance Cartridge
Ink used for maintenance purposes such as head cleaning is absorbed. (Replace the cartridge when it is full.)
l
Carrying Handles
When carrying the printer, have six people hold it by these handles under both sides.
m
Maintenance Cartridge Cover
Open this cover to replace the Maintenance Cartridge.
n
Stand
A stand that holds the printer. Equipped with casters to facilitate moving it.
o
Stand L
The left leg of the Stand.
p
Stand R
The right leg of the Stand.
q
Leg Covers
Covers for Stand L and Stand R.
r
Stopper
Locks the Stand casters.
Always release the Stopper before moving the printer. Moving the printer while the Stopper is locked may
scratch the casters or the floor.
s
Roll Unit
A unit for loading two rolls.
Front
iPF840 Series
Basic Guide
Printer Parts Printer parts
68
