Canon imagePROGRAF TM-305 Service Guide

Canon imagePROGRAF TM-Series Service Guide
imagePROGRAF TM-Series Service Guide June 2021
Revision 4 Page 5
Table 2 -Hardware Option
Item
Item Number
2
Printer Stand SD-22 (imagePROGRAF TM-200 without stand only)
3085C001AA
Roll Holder Set RH2-28 (imagePROGRAF TM-200 only)
1153C005AA
Roll Holder Set RH2-35 (imagePROGRAF TM-305/TM-300 only)
1153C006AA
Maintenance Cartridge MC-31 1156C005AB
Cutter Blade CT-08 1155C002AA
Z36 Calibration Target 1691B123AA
Z36 Scanner Glass 1691B124AA
Z36 Hold-up Plate
1691B125AA
Z36 Document Return Guides (Pack of 3) 1691B126AA
Z36 Keyboard Tray 1691B112AA
Colortrac SC 42c Xpress Scanner (No Stand)
6
1691B088AA
Colortrac Repro Stand
1691B090AA
Colortrac Floor Stand 1691B106AA
Colortrac Document Return Guide 1691B107AA
2 Item Numbers and Part Numbers are subject to change without notice.
Table 3 – Contour Cutter
Item
Item Number
2
Cutter Blade for CE6000 (2pk) 4511C003AA
Teflon Mat for CE6000-60 (2pk) 4511C004AA
Teflon Mat for CE6000-120 (2pk) 4511C005AA
CE7000-60 Plus 24” Contour Cutter and Colorbyte R.E.D. Software 4511C007AA
CE7000-60 Plus Stand (Optional 24” Stand) 4511C008AA
CE7000-130 Plus 50” Contour Cutter and Colorbyte R.E.D. Software 4511C009AA
Teflon Mat for CE7000-60 (2 Pack) 4511C010AA
Teflon Mat for CE7000-130 (2 Pack)
4511C011AA
CB15U Blade
7
4511C012AA
PHP33-CB15N-HS Blade Holder
7
4511C013AA
2 Item Numbers and Part Numbers are subject to change without notice.
Table 4 - Software Option
Item Item Number
2
PosterArtist
7025A039BC
SmartWorks MFP Plus
7025A042BA
Colorbyte IMAGEPRINT R.E.D. Software
7025A046AA
2 Item Numbers and Part Numbers are subject to change without notice.
6
Refer to the Colortrac SC 42c Xpress Scanner Service Support Guide to prepare for installation, service and training
requirements.
7
Compatible with the CE7000-60 Plus 24" Contour Cutter and CE7000-130 Plus 50" Contour Cutter.

Canon imagePROGRAF TM-305 Specifications

General

Max Print Resolution	2400 x 1200 dpi
Connectivity	USB, Ethernet, Wi-Fi
Printer Type	Large Format Printer
Ink Droplet Size	5 picoliters
Memory	2 GB
Operating System	Windows, Mac OS
Power Supply	AC 100-240V, 50/60Hz
Number of Ink Colors	5
Media Handling	Roll feed
Max Media Width	36 inches
Hard Drive	500 GB
Number of Nozzles	15, 360
Nozzle Pitch	1200 dpi
Ink Tank Capacity	130 ml per color
Media Thickness	0.07 to 0.8 mm
Media Core Size	2 inches
Media Sizes	A4, A3, A2, A1, A0
Media Types	Plain Paper, Coated Paper, Glossy Photo Paper, Satin Photo Paper
Ink Type	Pigment ink
