Table 35 - Lei Series Scanner Specifications
Colortrac Lei Series Scanner Specifications
Item
Scanner
L36ei Scanner
L24ei Scanner
Scan
Speed
17
COPY
300/300dpi Standard:
• Color: up to 1” per second
• Monochrome: up to 3” per second
300/600dpi High:
• Color up to 1” per second
• Monochrome up to 3” per second
600/600dpi Best:
• Color up to 0.5” per second
•
Monochrome up to 1.5” per second
SCAN
200dpi Standard:
• Color up to 1” per second
• Monochrome up to 3” per second
300dpi High:
• Color up to 0.5” per second
• Monochrome up to 1.5” per second
600dpi Best:
• Color up to 0.33” per second
• Monochrome up to 1” per second
Illumination
96 LEDs
64 LEDs
Resolutions
Optical: 600 dpi
Scan Mode: 200/400/600dpi
Paper Path
Face up, rear exit. Forward document transport only.
Document return guide included. (1 for L24ei, 3 for L36ei)
Scan Width
Up to 36”
Up to 24”
Minimum Scan Width
Up to 6” (15 cm)
Up to 6.2” (16 cm)
Document Width
Up to 38” (965 mm)
Up to 26” (660 mm)
Maximum Scan Length
Up to 109” (2,768 mm)
Scan Accuracy
18
0.2% ; +/- 1 pixel
Media Thickness
Minimum: Approximately 0.003” (0.07 mm)
Maximum: Approximately 0.020” (0.50 mm)
Modes
• Scan to USB - RGB/Greyscale/BW, TIFF (No ScanApp Lei)
• Scan to USB - RGB/Greyscale/BW, JPG, PDF, M-PDF (ScanApp
Lei available)
• Scan to PC - RGB/Greyscale/BW, Tiff, JPEG, PDF, TiffG4, M-PDF
• Copy - RGB/Greyscale/BW
• Copy & Archive – (Combination of Copy and Scan to PC above).
• Cloud connectivity is achieved by using Direct Print & Share.
Operating Environments
10 – 35°C, 35-90% RH, Non-condensing
Acoustic Noise
50.6 dB gray scan
48.4 dB gray scan
Power Supply
External PSU: Input: 100-240 V, 50-60 Hz
Output: 3.42 at 19 V
Power Consumption
17.5 W (Scanning)
0.6 W (Standby)
11.7 W (Idle)
Compliances
VCCL, CB, CE, FCC, UL, ENERGY STAR, S mark, NOM-019-SCFI
17
The scan rate is proportional across the full range of resolutions supported by the scanner. Actual scan times will depend
on the host system performance.
Quoted top speeds may be limited by the effective bandwidth of the USB 2 and is not
guaranteed for all media types.
18
The quoted scan accuracy may vary depending on the operating environment and the thickness of the media.

Canon imagePROGRAF TM-305 Specifications

General

Max Print Resolution	2400 x 1200 dpi
Connectivity	USB, Ethernet, Wi-Fi
Printer Type	Large Format Printer
Ink Droplet Size	5 picoliters
Memory	2 GB
Operating System	Windows, Mac OS
Power Supply	AC 100-240V, 50/60Hz
Number of Ink Colors	5
Media Handling	Roll feed
Max Media Width	36 inches
Hard Drive	500 GB
Number of Nozzles	15, 360
Nozzle Pitch	1200 dpi
Ink Tank Capacity	130 ml per color
Media Thickness	0.07 to 0.8 mm
Media Core Size	2 inches
Media Sizes	A4, A3, A2, A1, A0
Media Types	Plain Paper, Coated Paper, Glossy Photo Paper, Satin Photo Paper
Ink Type	Pigment ink
