Canon imagePROGRAF TZ-30000 Setup Guide

9
7
Remove the orange protective caps in the order shown in
the diagram.
Hold here to
remove
Important
●Do not touch the part that was being
protected by the protective cap (part
shown shaded in the diagram) under any
circumstances. Touching it may cause damage
to the print head or printing problems.
●The print head is filled with ink. Be careful to
avoid getting your clothes and surrounding
items dirty when removing the protective
caps. It is recommended that you remove the
protective caps above the bag that contained
the print head.
●Do not reattach the protective caps after
removing them. Dispose of them according to
local regulations.
8
Install the print head.
●Align the print head so that the area enclosed by a circle in the
diagram is facing you, and carefully push the print head firmly
into the printer, ensuring that the part covered by the protective
caps does not touch the carriage.
9
Pull the print head locking cover down toward you to lock
the print head in place.
10
Push the print head lock lever all the way to the end.
11
Close the inner cover.
12
Close the top cover.

Canon imagePROGRAF TZ-30000 Specifications

General

Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Roll Feed	Yes
Connectivity	USB, Ethernet, Wi-Fi
Hard Drive	500 GB
Print Technology	Inkjet
Ink Type	LUCIA TD
Ink Palette	Cyan, Magenta, Yellow, Black
Ink Tank Capacity	330 ml
Number of Nozzles	15, 360 nozzles (total)
Media Handling	Roll Feed
Maximum Media Width	36 inches
Media Width	8 to 36 inches
Maximum Print Size	36 inches wide
Paper Sizes	A0, A1, A2, A3, A4, Custom
Paper Capacity	Roll: One Roll, Manual Feed: One Sheet
Cutter	Automatic cutter
Interface	USB 2.0, Ethernet, Wi-Fi
Memory	1 GB
