3-25
Print Plug-In for Photoshop
Chapter 3 Utilize Print Plug-In to Print
4. Set the roll paper options and click OK.
5. Select either Portrait or Landscape as the media orientation for the image in Orientation.
Setting Details
Roll Paper Width This selects the width of the roll paper set to the
printer.
Automatic Cutting Select either Yes, No or Print Cut Guideline to
activate automatic cutting.
No Spaces at Top or
Bottom (Conserve Paper)
When you place a checkmark here, you can print
without any margins at the top and bottom of an
image.
Note
• Refer to “Roll Paper Options Dialog Box” (p.2-10) for more information on
the Roll Paper Options dialog box.
• Click the Defaults button to return all of the roll paper option settings to
their defaults.
Note
• When you select Portrait, the image on the media prints as it appears on
the screen.
• When you select Landscape, the image on the media prints rotated 90
degrees.
To Next Page
