E503-0032-02 Error in communication between the Finisher and Puncher Unit (Finisher-AA1)
Detection Description Communication error between the Finisher Controller PCB and the Puncher Controller PCB was
detected. (Command reception error)
Remedy
STAPLE FIN-AA1/BOOKLET FIN-AA1
[Related parts]
- Harnesses and connectors from the Finisher Controller PCB to the Puncher Controller PCB
- Finisher Controller PCB (PCB101)
- Puncher Controller PCB (PCB301)
[Remedy] Perform the following in the order while checking whether the error is cleared.
1. Check/replace the harness and connector between the Finisher Controller PCB and the Puncher
Controller PCB.
2. Replace the Finisher Controller PCB.
[Reference] When replacing the Finisher Controller PCB, refer to "Adjustment> When Replacing
the Parts" in the Service Manual.
3. Replace the Puncher Controller PCB.
[Reference] When replacing the Puncher Controller PCB, refer to "Adjustment> When Replacing
the Parts" in the Service Manual.
E503-0041-02 Error in communication between the Finisher and Buffer Pass (Finisher-AA1)
Detection Description Communication error between the Finisher Controller PCB and the Buffer Pass Controller PCB
was detected. (Command transmission error)
Remedy
STAPLE FIN-AA1/BOOKLET FIN-AA1
[Related parts]
- Harnesses and connectors from the Buffer Pass Controller PCB to the Finisher Controller PCB
- Buffer Pass Controller PCB (PCB201)
- Finisher Controller PCB (PCB101)
[Remedy] Perform the following in the order while checking whether the error is cleared.
1. Check/replace the harness and connector between the Buffer Pass Controller PCB and the
Finisher Controller PCB.
2. Replace the Buffer Pass Controller PCB.
3. Replace the Finisher Controller PCB.
[Reference] When replacing the Finisher Controller PCB, refer to "Adjustment> Adjustment when
Replacing the Parts" in the Service Manual.
E503-0042-02 Error in communication between the Finisher and Buffer Pass (Finisher-AA1)
Detection Description Communication error between the Finisher Controller PCB and the Buffer Pass Controller PCB
was detected. (Command reception error)
Remedy
STAPLE FIN-AA1/BOOKLET FIN-AA1
[Related parts]
- Harnesses and connectors from the Buffer Pass Controller PCB to the Finisher Controller PCB
- Buffer Pass Controller PCB (PCB201)
- Finisher Controller PCB (PCB101)
[Remedy] Perform the following in the order while checking whether the error is cleared.
1. Check/replace the harness and connector between the Buffer Pass Controller PCB and the
Finisher Controller PCB.
2. Replace the Buffer Pass Controller PCB.
3. Replace the Finisher Controller PCB.
[Reference] When replacing the Finisher Controller PCB, refer to "Adjustment> Adjustment when
Replacing the Parts" in the Service Manual.
E503-0061-02 Error in communication between the IC of Finisher Controller PCB (Finisher-AA1)
Detection Description Communication error between the IC of Finisher Controller PCB was detected. (Command
transmission error)
Remedy
STAPLE FIN-AA1/BOOKLET FIN-AA1
[Related parts]
- Finisher Controller PCB (PCB101)
[Remedy] Replace the Finisher Controller PCB.
[Reference] When replacing the Finisher Controller PCB, refer to "Adjustment> When Replacing
the Parts" in the Service Manual.
7. Error/Jam/Alarm
390
