E554-8001-02 Safety switch ON error (Finisher-AA1)
Detection Description The Swing Guide Safety Switch is turned ON for 0.3 seconds.
The Front Cover Switch is turned OFF for 0.3 seconds when the Front Cover Sensor is ON.
Remedy
STAPLE FIN-AA1/BOOKLET FIN-AA1
[Related parts]
- Harnesses from the Swing Guide Safety Switch (SW102) to the Finisher Controller PCB
- Harnesses from the Stack Tray Shift Motor (M105) to the Finisher Controller PCB
- Swing Guide Safety Switch (SW102)
- Stack Tray Shift Motor (M105)
- Finisher Controller PCB (PCB101)
[Remedy] Check/replace the related harness/cable, connector and parts.
[Reference] When replacing the Finisher Controller PCB, refer to "Adjustment> When Replacing
the Parts" in the Service Manual.
E577-0002-02 Paddle Motor error (Finisher-K1)
Detection Description - The Return Belt HP Sensor was not turned ON although 1 second had passed after the Paddle
Motor operation started.
- The last paddle operation is not finished when driving the Paddle Motor.
Remedy
INNER FIN-K1
[Related parts]
- Harnesses and connectors from the Finisher Controller PCB to the Return Belt HP Sensor
- Harnesses and connectors from the Finisher Controller PCB to the Paddle Motor
- Return Belt HP Sensor (PS3)
- Paddle Motor (M10)
- Finisher Controller PCB (PCB1)
[Remedy] Check/replace the corresponding harnesses/cables or connectors or the parts.
[Reference] When replacing the Finisher Controller PCB, refer to "Adjustment> Adjustment when
Replacing the Parts" in the Service Manual.
E577-8001-02 a. Paddle Motor error (Finisher-K1) b. Error in the Stack Delivery/Paddle Motor (Finisher-
AA1)
Detection Description a. The Return Belt HP Sensor was not turned ON although 1 second had passed after the Paddle
Motor operation started. The last paddle operation is not finished when driving the Paddle Motor.
b. The paddle does not come off the Paddle HP Sensor when the Stack Delivery/Paddle Motor
has been driven for 1 second.
Remedy
a. INNER FIN-K1
[Related parts]
- Harnesses and connectors from the Finisher Controller PCB to the Return Belt HP Sensor
- Harnesses and connectors from the Finisher Controller PCB to the Paddle Motor
- Return Belt HP Sensor (PS3)
- Paddle Motor (M10)
- Finisher Controller PCB (PCB1)
b. STAPLE FIN-AA1/BOOKLET FIN-AA1
[Related parts]
- Harnesses from the Paddle HP Sensor (PS120) to the Finisher Controller PCB
- Harnesses from the Stack Delivery/Paddle Motor (M103) to the Finisher Controller PCB
- Paddle HP Sensor (PS120)
- Stack Delivery/Paddle Motor (M103)
- Finisher Controller PCB (PCB101)
[Points to note at work] When the Swing Guide Safety Switch (SW102) turns on at the detection
timing of this error, this error code may be displayed. Accordingly, perform the following work before
checking the related parts.
1. Check whether there is not the mulfunction in the swing guide unit.
2. Check whether there is not the mulfunction in the Swing Guide Safety Switch (SW102).
[Remedy] Check/replace the related harness/cable, connector and parts.
[Reference] When replacing the Finisher Controller PCB, refer to "Adjustment> When Replacing
the Parts" in the Service Manual.
7. Error/Jam/Alarm
404
