CHAPTER 11 INSTALLATION
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000/iR1610/iR2010 SERIES REV.0 MAR. 2002
11-29
5.2 Installation
1) Remove the 7 screws [1], and detach the
rear cover [2].
F11-502-01
2) Remove the 5 screws [3], and detach the
right cover [4].
F11-502-02
[1]
[1]
[1]
[1] [2]
[3]
[4]
