Canon iR8500 User Manual

CHAPTER 4 INSTALLATION
4-39
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON iR8500/7200 REV.1 AUG. 2001
5 Holding the grips on the pickup side
(front, rear) for the copier, lift the machine
slightly to remove the pad [1].
At this time, move the plastic bag [2]
toward the remaining pad.
No. Work Checks/remarks
4 Open the right upper cover, and slide the
small face cover [1] to the rear to detach;
then, detach the large face cover [2].
Fit the grip [3] detached in step 3 at the
front.
Close the right upper cover.
F04-302-04
F04-302-05
[1]
[3]
[2]
[1]
[2]

Canon iR8500 Specifications

General

Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Grayscale Halftones	256 Levels
Duplexing	Yes
Functions	Print, Copy, Scan
Maximum Original Size	11" x 17"
Copy Size	11 x 17 inches
Connectivity	USB, Ethernet
Operating System Compatibility	Windows, Mac
Supported Media Sizes	Letter, Legal
