(13/58)
4-2) When the Easy-Scroll Wheel is rotated clockwise 1 round (16 steps), press the OK button.
4-3) Rotate the Easy-Scroll Wheel counterclockwise step by step. The LCD is divided into 16
segments, representing each step. The color of a segment corresponding to the step
changes from green to blue.
If the wheel is rotated clockwise before counterclockwise round completes, the color of
segment(s) corresponding to the number of steps the wheel is rotated clockwise returns to
green.
If the wheel keeps rotated counterclockwise over 1 round (16 steps), the color of
segment(s) corresponding to the extra number of steps returns to green, starting with the
"Start" segment in the figure below.
4-4) When the Easy-Scroll Wheel is rotated counterclockwise 1 round (16 steps, and all the
segments are in blue), press the OK button. The color pattern is displayed on the LCD.
If there is any segment that is not in blue when the OK button is pressed, the display
remains unchanged.
5) Adjust the transparent color, as follows:
5-1) Press the OK button. "OK1" in white is displayed on the black background.
If the result is not good, "NG1" in black is displayed on the white background (transparent
color) immediately after "OK1."
