CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-12
2) Put the cable drive pulley [1] into the shaft [4], and secure it in position with an E-ring [5].
When putting the cable drive pulley into the shaft, be sure that the hook is at the front.
Figure 2-20
3) Hook the shorter end [6] on the pulley [7].
Figure 2-21
[5]
Hook
(front)
[1]
[4]
[7]
[6]
