CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-19
7) Hook the end of the shorter end [3] on the hole [13] on the right side.
Figure 2-33
8) Free the shorter end [3] and the longer end [5] (reversing cable), and connect both with a spring
[14]; then, fit the stopper [15].
Figure 2-34
[3] [13]
[14]
[3]
[15]
[5]
