Canon Pixma G2430 User Manual

Canon IJ Status Monitor Description
The Canon IJ Status Monitor displays the printer status and the printing progress. The printer status is
shown by the icons and messages in the status monitor.
Features of the Canon IJ Status Monitor
The Canon IJ Status Monitor has the following functions:
Onscreen display of printer status
The status monitor displays the printer status in real-time.
You can check the progress of each document to be printed (print job).
Display of error content and correction procedure
The status monitor displays information on any errors that occur on the printer.
You can then immediately check what sort of action to perform.
Overview of the Canon IJ Status Monitor
The Canon IJ Status Monitor displays icons and messages related to printer status and ink.
During printing, you can check information about the document being printed and the print progress.
If an error occurs, the status monitor displays the error content and instructions on how to correct the
error. Follow the message instructions.
Printer
Canon IJ Status Monitor shows an icon when a warning or error occurs to the printer.
: There is a warning.
: There has been an operator error.
: There is a notice about something other than a warning or an error.
: There has been an error which requires a service.
198

Canon Pixma G2430 Specifications

General

Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Borderless printing	Yes
Duplex printing mode	Manual
Print speed (ISO/IEC 24734) mono	11 ipm
Print speed (ISO/IEC 24734) color	6 ipm
Print speed (black, normal quality, A4/US Letter)	- ppm
Envelopes sizes	10, C5, DL
Custom media width	55 - 216 mm
Custom media length	89 - 1200 mm
Paper tray media types	Envelopes, Photo paper, Plain paper
Paper tray media weight	64 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Photo paper sizes (imperial)	4x6, 5x7, 7x10, 8x10 \
Borderless printing media sizes	A4, B5, Letter
Maximum ISO A-series paper size	A4
Total input capacity	100 sheets
Total output capacity	- sheets
Total number of input trays	1
Scanner type	Flatbed scanner
Duplex scanning	-
Input color depth	16 bit
Output color depth	8 bit
Optical scanning resolution	600 x 1200 DPI
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
USB connector	USB Type-B
Mac operating systems supported	Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Other operating systems supported	ChromeOS
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supported	Windows 10, Windows 11, Windows 8.1
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (copying)	15 W
Power consumption (standby)	0.6 W
Energy Star Typical Electricity Consumption (TEC)	0.09 kWh/week
Wi-Fi	No
Product color	Black
Market positioning	Home & office
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	557 mm
Width	416 mm
Height	268 mm
