Canon PIXMA MP210 Series Setup Instructions

Windows
Macintosh
Note
ThescreensbelowrefertoWindowsVista™operatingsystemUltimateEdition
(hereafterreferredtoas“WindowsVista”)installation.
Screensmayvarydependingontheoperatingsystemyouareusing.
Logintoauseraccountwiththeadministratorprivilege.
Beforeinstallingthesoftware,disableallanti-virusprogramsandautomatically
loadingprograms.
Amessageaskingforyourconfirmationtorestartyourcomputermayappear
duringtheinstallationprocess.Ifthismessageisdisplayed,followtheon-screen
instructionsandclickOK.
The installationresumesfromwhereitleftoffwhenyourcomputerhasbeenrestarted.
aBesuretoTURN THE MACHINE OFFbeforecontinuing.
(1) PresstheON/OFFbutton.
(2) MakesurethatthePowerlampstopsashing.
bTurnthecomputeronandstartWindows.
Important
If the Found New Hardware or Found New Hardware Wizard screen appears
automatically, remove the USB cable connected to your computer. Click Cancel
to quit the screen. In Windows Vista, the screen may close automatically when
the USB cable is unplugged. Then turn off the machine and proceed from step
c to install the software.
cInserttheSetupCD-ROM.Thesetupprogramshouldrun
automatically.
InWindowsVista,gotoStepd.InWindowsXPandWindows2000,goto
Step
f.
dIftheAutoPlayscreenappears,clickRun Msetup4.exe.
eIftheUser Account Controlscreenappears,clickContinue.
Ifthesamescreenreappearsinsubsequentsteps,click
Continue.
fWhenthemainmenuappears,clickEasy Install.
TheMPDrivers,On-screenManuals,andapplicationsoftwareareinstalled
automatically.
Note
Ifyouwanttoselectparticularitemstoinstall,clickCustom Installandfollowtheon-
screeninstructionstoproceedtheinstallation.
•
•
•
•
gWhenthelistofapplicationstoinstallappears,conrmthe
contents,click
Install.
Note
Movethecursoroveritemstodisplayexplanationsofeachapplication.
hReadtheLicenseAgreementcarefullyandclickYes.The
softwareinstallationscreenmayappearduringtheinstallation
process.Followtheon-screeninstructionstoinstallthe
software.
iWhenthePrinter Connectionscreenappears,connect
oneendoftheUSBcabletothecomputer,theothertothe
machine,then
TURN THE MACHINE ON.TheMPDriverswill
beginidentifyingtheprinterportbeingused.
Important
If you cannot go to the next procedure after three minutes, refer to “Trouble-
shooting” instructions in the User’s Guide on-screen manual.
USB
ToComputer
→
jWhenthePrint Head Alignment Recommendedscreen
appears,click
Next.
kWhentheSetup Completescreenappears,clickNext.
lWhentheUser Registrationscreenappears,clickNext.
Note
Toregisterlater,clickCancelandgotoStepm.Aftersoftwareinstallationiscomplete,
double-click onthedesktop.
Followon-screeninstructionstoregisteryourproduct.Youwillneedyour
productserialnumber,whichislocatedontheinsideofthemachine.See
Step1-
honthefrontpage.
mWhenthePIXMA Extended Survey Programscreen
appears,conrmthemessage.Wewouldappreciateitifyou
wouldtakepartinthisprogramregardingtheuseofCanon
printers.Ifyoucanagree,click
Agree.
nWhentheInstallation completed successfullyscreen
appears,click
Exit.
IfRestartisdisplayed,makesurethattheRestart the system now
(recommended)checkboxisselected,thenclickRestart.
Note
IfstraightlinesaremisalignedorprintqualityisnotsatisfactoryafterinstallingtheMP
Drivers,youmayneedtoalignthePrintHead.Referto“Aligning the Print Head” in
the Quick Start Guide.
Software installation is now complete.
Windows
®
Software Installation
Note
SinceMac
®
OS9,MacOSXClassicenvironments,orMacOSXv.10.2.7orearlier
arenotsupported,donotconnectthemachinetothese.
ThescreensbelowrefertoMacOSXv.10.4.xinstallation.Screensmayvary
dependingontheoperatingsystemyouareusing.
LogonasanAdministrator.
Beforeinstallingthesoftware,disableallanti-virusprogramsandautomatically
loadingprograms.
aConnectoneendoftheUSBcabletothecomputerandthe
othertothemachine.
Note
Makesurethemachineisturnedon.
USB
bTurnonyourMacandinserttheSetupCD-ROM.
Note
IftheCD-ROMfolderdoesnotopenautomatically,double-clicktheCD-ROMicon
onthedesktop.
cDouble-clicktheSetupicon.
dWhentheAuthenticatescreenappears,enteryour
administratornameandpassword.Click
OK.
Ifyoudonotknowyouradministratornameorpassword,click
,thenfollowtheon-screeninstructions.
eWhenthemainmenuappears,clickEasy Install.
TheMPDrivers,On-screenManuals,andapplicationsoftwareareinstalled
automatically.
Note
Ifyouwanttoselectparticularitemstoinstall,clickCustom Installandfollowtheon-
screeninstructionstoproceedtheinstallation.
fWhenthelistofapplicationstoinstallappears,conrmthe
contents,thenclick
Install.
Note
Movethecursoroveritemstodisplayexplanationsofeachapplication.
gReadtheLicenseAgreementcarefullyandclickYes.The
softwareinstallationscreenmayappearduringtheinstallation
process.Followtheon-screeninstructionstoinstallthe
software.
hWhenthePrint Head Alignment Recommendedscreen
appears,click
Next.
iWhentheSetup Completescreenappears,clickNext.
•
•
•
•
Macintosh
®
Software Installation
jWhentheUser Registrationscreenappears,clickNext.
Note
Toregisterlater,clickCancelandgotoStepk.Aftersoftwareinstallationiscomplete,
double-click onthedesktop.
Followon-screeninstructionstoregisteryourproduct.Youwillneedyour
productserialnumber,whichislocatedontheinsideofthemachine.See
Step1-
honthefrontpage.
kWhentheInstallation completed successfullyscreen
appears,click
Restart.
Thesystemisrestartedautomatically.
When using Mac OS X v.10.2.8 to v.10.3.3:
Restartingthecomputerwhileconnectedtothemachinemaycausethe
machinenottobedetected.Toresolvethis,eitherunplugtheUSBcable
thenplugitbackinagain,orturnthemachineoffthenbackonagain.
Note
WhenusingMacOSXv.10.2.8tov.10.3.x,beforeusingtheOperationPanelon
themachinetosaveoriginalsscannedfromthePlatenGlasstothecomputer,it
isnecessarytoselectMP Navigator EX 1.0orMP Navigator EX 1asthelaunch
applicationonImageCaptureunderApplications.Fordetails,referto“Scanning
Images” in the User’s Guideon-screenmanual.
Ifstraightlinesaremisalignedorprintqualityisnotsatisfactoryafterinstallingthe
MPDrivers,youmayneedtoalignthePrintHead.Referto“Aligning the Print
Head” in the Quick Start Guide.
Software installation is now complete.
•
•
Partno.
QT5-1206-V01©2007CanonInc.“Microsoft”isaregisteredtrademarkofMicrosoftCorporation.“Windows”isatrademarkofMicrosoftCorporation,registeredintheU.S.andothercountries.“WindowsVista”isatrademarkofMicrosoftCorporation.“Macintosh”and“Mac”aretrademarksofAppleInc.,registeredintheU.S.andothercountries.
XXXXXXXXPRINTEDINVIETNAM

Canon PIXMA MP210 Series Specifications

General

Print Technology	Inkjet
Max Print Resolution	4800 x 1200 dpi
Functions	Print, Scan, Copy
Print Speed (Black)	22 ppm
Print Speed (Color)	17 ppm
Scanner Type	Flatbed
Max Scan Resolution	1200 x 2400 dpi
Copy Speed (Black)	22 cpm
Copy Speed (Color)	17 cpm
Copy Resolution	600 x 600 dpi
Interface	USB 2.0
Paper Sizes	Letter, Legal
Operating System Support	Mac OS
Ink Cartridge Compatibility	PG-40, CL-41
