2.2 Manual Capping
The BJ cartridges of the BJC-7100 printer can be capped manually only by service
personal.
1) Insert a tweezers into the hole for manual capping positioning and rotate the gears
slowly counterclockwise.
2) When the cap and carriage lock lever are in the lowest position, slowly move the
carriage to the capping position. *
3) Next, use the tweezers to slowly rotate the gears counterclockwise. Stop rotating the
gears when you can see that capping has been completed.
4) The print head is capped and the carriage is locked.
3-13
BJC-7100
Part 3: Operating Instructions
