External Connections
Video Output Configuration
The video signal output from the SDI terminal and HDMI
TM
OUT terminal, depends on the clip’s video
configuration and on various menu settings.
Recording Video Signal Configuration and Video Output Configuration by Terminal
Refer to the following table for the video output configuration from each terminal, depending on the recording
video configuration used.
Operating modes:
Recording video configuration Menu settings Video output configuration
Video format
1
Frame rate
Resolution/
Color sampling
Scan mode
2
Maximum
resolution
3
SDI terminal
HDMI OUT
terminal
XF-HEVC
59.94P
50.00P
3840x2160
YCbCr 4:2:2
10 bit
P
3840x2160 3840x2160 (59.94P/50.00P)
1920x1080 1920x1080 (59.94P/50.00P)
PsF — 19 20x1080 (59.94i/50.00i)
29.97P
25.00P
P
3840x2160 3840x2160 (29.97P/25.00P)
1920x1080 1920x1080 (29.97P/25.00P)
PsF —
1920x1080
(29.97PsF/25.00PsF)
1920x1080
(59.94i/50.00i)
23.98P
P
3840x2160 3840x2160 (23.98P)
1920x1080 1920x1080 (23.98P)
PsF — 1920x1080 (59 .94i)
59.94P
50.00P
1920x1080
YCbCr 4:2:2
10 bit
P — 1920x1080 (59.94P/50.00P)
PsF — 19 20x1080 (59.94i/50.00i)
59.94i
50.00i
— — 1920x1080 (59 .94i/50.00i)
29.97P
25.00P
P — 1920x1080 (29.97P/25.00P)
PsF —
1920x1080
(29.97PsF/25.00PsF)
1920x1080
(59.94i/50.00i)
23.98P
P — 1920x1080 (23.98P)
PsF — 1920x1080 (59 .94i)
XF-AVC
59.94P
50.00P
1920x1080
YCbCr 4:2:0
8bit
P —
1920x1080 (59.94P/50.00P)
720x480 (59.94P)
4
720x576 (50.00P)
4
PsF — 19 20x1080 (59.94i/50.00i)
29.97P
25.00P
P — 1920x1080 (29.97P/25.00P)
PsF —
1920x1080
(29.97PsF/25.00PsF)
1920x1080
(59.94i/50.00i)
23.98P
P — 1920x1080 (23.98P)
PsF — 1920x1080 (59 .94i)
