Capacity TJ5000 DOT - Control Panel Layout

Capacity of Texas, Inc.
6
Figure 2-1 Controls and Indicators.
Table 2-1 Controls & Indicators
Item Name Function
1 Status LED Panel 1 Multiple LEDs indicate various conditions.
Refer to Figure 2-2 for more information
2 Tachometer Indicates engine speed in RPM
