XVII. WINTERIZING 61
Blocking the Hull 61
Bottom Haulout 62
Propeller and Cutless Bearing 62
Engine 62
Fuel Tanks 62
Head 63
Electrical System 63
Scuppers and Seacocks 63
Ice Box 63
Bilge 63
Stove 63
Covering 63
Mast and Boom 64
XVIII. VENDOR PARTS LIST 65
XIX. VENDOR ADRESSES 69
XX. TECHNICAL INFORMATION 70
XXI. TECHNICAL REFERENCE DRAWINGS 71
1. Sail Plan 71
2. Arrangement 72
3. Starboard Elevation 73
4. Hull Deck Joint at Upper Shroud 74
5. Hull Deck Joint at Lower Shroud 75
6. Mast Step Detail 76
7. Stemhead Detail 77
8. Deck Hardware Layout 78
9. Steering System – Tiller 79
10. Steering System – Wheel 80
11. Spar Plan 81
12. Mainsheet Rigging Detail 82
13. Centerboard - System A 83
14. Centerboard - System B 84
15. Seacock Detail 85
16A. Fresh Water System 86
16B. Waste & Discharge System 87
17A. Fuel System 88
17B. Engine Cooling & Hot Water System 89
18. DC Panel Wiring 90
19A. 12 Volt DC Wiring 91
19B. 110 Volt AC Wiring 92
20. Lightning Ground & Underwater Bonding 93
21. Lifting Strap Location 94
