Instruction manual C995i 23
Please keep this instruction manual for future reference
INSTALLATION
SELECTION OF INSTALLATION EQUIPMENT
Cut out the work surface according to the sizes shown in the drawing. For the purpose of
installation and use, a minimum of 50mm space shall be preserved around the hole. Be sure the
thickness of the work surface is at least 30mm. Please select heat-resistant work surface material
to avoid larger deformation caused by the heat radiation from the hob. As shown below:
A
B
D
F
E
A (mm) 272
B (mm) 504
C (mm) 50
D (mm) 50
E (mm) 50
F (mm) 50
