Instruction manual CM108 11
Please keep this instruction manual for future reference
INSTALLATION
IMPORTANT:
Isolate your microwave oven from the electrical supply before performing installation
or maintenance.
Installation should be carried out according to the instructions by a professionally qualified
person only.
The manufacturer declines all responsibility for any damage to persons, animals or materials due
to incorrect installation.
FITTING THE APPLIANCE:
Fit the appliance into its surround
(beneath a worktop or above another
appliance in a tall housing) by
inserting screws and plastic covers
into the 4 holes (A - fig.3) that can be
seen in the frame of the oven when
the door is open.
For the most efficient air
circulation, the microwave oven
should be fitted according to the
dimensions shown in fig.1.
548mm
22mm
8.6mm
454mm
min. 550mm
565mm
595mm
450mm
70mm
Ventilation Slot
70mm
23mm
Plastic cover
Fig.3
Fig.1
