Caple CM108BG - Installation

Instruction manual CM108BG 11Please keep this instruction manual for future reference
INSTALLATION
IMPORTANT:
Isolate your microwave oven from the electrical supply before performing installation
or maintenance.
Installationshouldbecarriedoutaccordingtotheinstructionsbyaprofessionallyqualied
person only.
The manufacturer declines all responsibility for any damage to persons, animals or materials due
to incorrect installation.
FITTING THE APPLIANCE:
Fit the appliance into its surround
(beneath a worktop or above another
appliance in a tall housing) by
inserting screws into the 4 holes
(A-g.3)thatcanbeseeninthe
frame of the oven when the door is
open.
Forthemostefcientair
circulation, the microwave oven
shouldbettedaccordingtothe
dimensionsshowning.1.
min. 550
mm
565mm
450mm
50mm
Ventilation Slot
50
mm
547.4mm
22mm
8.6mm
453.6mm
441mm
21.6mm
595mm
540mm
Fig.1
