3
1
2
2
1
2
Instruction manual DD780BK Please keep this instruction manual for future reference14
ASSEMBLING THE EXTRACTION UNIT
Assemble the extraction unit towards the induction hob bottom cover. Use firstly the screws (3)
and washers (2), then the screws (1) and the washers (2) included in the assembling kit.
INSTALLING THE HOB
The appliance is supplied with an installation kit including adhesive sealing material, fixing
brackets and screws.
Apply the supplied one-sided self-adhesive sealing tape (1) all the way around the lower edge of
the hob. Do not stretch the tape.
Screw the 4 worktop mounting brackets (2) into the side walls of product.
