19Instruction manual WDi3301Please keep this instruction manual for future reference
BUILT IN INSTALLATION
Before installing the washer dryer, please read these built-in instructions carefully and keep for
future reference. This appliance has been designed to be built into the kitchen furniture. The
recess should have the dimensions as shown in the figure below:
WARNING:
When installing the appliance into the kitchen, if possible, ensure the hoses are placed in either
of the two recesses on the back of the appliance. This will help to prevent the hoses from being
kinked or trapped.
540mm
152.5mm
min. 825mm
600mm
595mm
560mm
825-835mm
