Installing the bar handle
Remove the door gasket on the drilling holes side to install the handle. (see below drawing). Fix the
handle to the screws and push the gasket back into place.
Installing the decorative frame
Take out the decorative frame and the brackets from the accessories box. Fix the brackets to the
cabinet with screws provided and fix both sides of the decorative frame to the brackets with the 2
supplied screws as shown in below diagram.
Screw
Screw
Decorative
fram e
The decorative
fram e bracket
8
Front
Back
