Caple WI6136 - Fitting a Kitchen Plinth

19Instruction manual Wi6135 Wi6135GM Wi6136Please keep this instruction manual for future reference
FITTING A KITCHEN PLINTH
This model is also supplied with a slot-on plinth grille if the previous method/grille is not
preferred. A H55mm vent slot is required in the plinth to ensure air is able to ventilate correctly.
See diagram below.
Wi6120
55
his model is also supplied with a slot on plinth grille if the previous method/grille is not preferred.
A H75mm vent slot is required in the plinth to ensure air is able to ventilate correctly. See diagram
below.
"
