Shipping Box 2 Contains
X-Axis Gantry Assembly Hybrid Table Extrusions and MDF Strips (Nested Together)
Hybrid Table Hardware Box
Shipping Box 1 Contains
Open Me First Box
• Tool Bag
• Extra Hardware Bag
• Zip Ties & Cable Ties
• #201 0.25″ Flat Endmill
• Workholding Kit
• Sweepy 65 V2.0 Box
• Sharpie
HDZ (Z-Axis) Box
• Pre-assembled HDZ (Z-Axis)
• HDZ Hardware Bag
• End Caps (Y-Left and Y-Right)
• End Cap Hardware Bag
• X-Axis Stepper Motor
• X-Axis Stepper Motor Hardware Bag
S5 Electronics Box
• Wiring Harness Box
• Wiring Harness
• Drag Chain Hardware Bag
• X- and Y-Axis Router Drag Chains
• Front Plate Extension Cable
• Grounding Block and Hardware
• Power Pendant Box
• Power Pendant
• Power Pendant Extension Cable
• Controller Box
• Controller
• USB Cable
• 3-prong Power Cable
• BitSetter Box
• BitSetter
• BitSetter Hardware
• BitSetter Extension Cable
Y-Left Assembly
Y-Axis Assembly Hardware Bag
Y-Right Assembly
Baseframe Box
• Baseframe Members
Cable Track (Underneath Baseframe Box)
Inventory
PRO TIP: Your Shapeoko5Pro kit has been carefully packaged by hand. If you find that you’re missing hardware
in any step, check the extra hardware bag included in the Open Me First Box. If you don’t find what you need in the
extra hardware bag, or one of your components was damaged in shipping, contact us at support@carbide3d.com
and we’ll ship you a replacement ASAP.
Welcome and Congratulations
The Shapeoko5Pro is a high-performance CNC router that comes with everything you need to accurately
cut wood, plastic, and aluminum, so you can turn your workbench into a business. At up to 4 feet in width,
Shapeoko5Pro is bigger than ever, so you can take on larger jobs or nest more parts together and run the
machine longer. It’s not just a CNC router, it’s a complete system of hardware, software, accessories, and
training, built and supported in the USA.
Assembly Notes
• We’ll walk you through the assembly process step-by-step in this guide. Precision-machined parts and
pre-assembled components, mean quicker assembly, in fewer steps!
• The use of power tools is not recommended for assembly. Use hand tools only.
• Some steps rely on non-tightened fasteners. Do not tighten fasteners beyond finger-tight until instructed.
• See the Glossary of Terms at the end of this guide for common CNC terms and definitions.
• Your Shapeoko5Pro gantry is powered by stepper motors. When the power is o, moving the motors by
hand will cause them to generate electricity. IMPORTANT: When moving the gantry by hand, go slowly. The
power generated by the stepper motors will feel like bumps. If the red LED on the controller lights up when
moving the stepper motors, it’s important to slow down because you are pushing electricity back through the
board. Too much backflow could damage the controller.
Software Requirements
The Shapeoko5Pro controller must be used with the latest version of Carbide Motion.
Support, Warranty, and Training
Technical Support
Have questions? Need help? We have a fully-staed support team waiting to help if you run into any trouble
while assembling your Shapeoko5Pro. Just email us at support@carbide3d.com.
One-Year Warranty
Your Shapeoko5Pro comes with a one-year warranty against defects. If you have any problems, we’ll take care
of them. See the full warranty at carbide3d.com/policy/warranty.
30-Day, “Mistakes Are on Us” Guarantee
We want you to jump into your new Shapeoko CNC router without any fear of damaging anything so our
warranty includes the following benefit: for the first 30 days that you own your Shapeoko, we’ll replace any
Carbide 3D-branded item that’s damaged, even if it’s your fault. Details about what’s covered can be found at
shop.carbide3d.com/pages/mistakes-are-on-us.
Free 1-on-1 Training Sessions
Your Shapeoko5Pro comes with four FREE 30-minute 1-on-1 training sessions with a Carbide 3D expert via
video chat.
Training Videos and More
Access training videos, design resources, and more at my.carbide3d.com.
