Belted-X/Z Proximity Switch Upgrade Kit Contents
The proximity switch upgrade kit comes with the components listed in the table below and shown in Fig. 1.
Item
Description
Qty
A
X-Axis Proximity Switch (2675mm for XXL, 2350mm for XL, and 610mm for Shapeoko 3)
1
B
Y-Axis Proximity Switch (2540mm for XXL, 2220mm for XL, and 712mm for Shapeoko 3)
1
C
Z-Axis Proximity Switch (2675mm for XXL, 2350mm for XL, and 610mm for Shapeoko 3)
1
X-Axis Proximity Switch Mount Baggie
D
X-Axis Proximity Switch Mount
1
E
M5 × 25mm Socket Head Cap Screw
2
F
M3 × 18mm Socket Head Cap Screw
2
Y-Axis Proximity Switch Mount Baggie
G
Y-Axis Proximity Switch Mount
1
H
M5 × 35mm Socket Head Cap Screw
2
I
M3 × 18mm Socket Head Cap Screw
2
Z-Axis Proximity Switch Mount Baggie
J
Z-Axis Proximity Switch Mount
1
K
M5 × 10mm Socket Head Cap Screw
4
L
M3 × 18mm Socket Head Cap Screw
2
M
PCB Riser Board
1
Drag Chain Baggie
N
Tail Plate
2
O
M3 × 6mm Flat Head Screw
2
P
Double-sided VHB Tape
2
Q
Alcohol Wipes
2
R
M3 × 8mm Flat Head Screw (Replacement)
4
S
M3 Nyloc Nut (Replacement)
4
T
4” Cable Ties (Pack of 100)
1
NOTE: Replacement M3×8mm FHS (4) and M3 nyloc nuts (4), for re-installing the drag chain to the X- and
Y-Axis head brackets, are included so you don’t have to keep track of tiny screws and nuts during the upgrade.
