12 Controller Fault
12.1 Fault Code Diagnostic Table
Error Code Explanation Actions
S.br
Temperature sensor failure
Check all terminal connections between the
temperature sensor (thermocouple) and temperature
controller (301). It is recommended to loosen then
tighten the screws in the terminal blocks in case the
connections are oxidised.
If this does not correct the error then replace the
furnace or oven temperature sensor (thermocouple).
oooo
Input over range
-ooo
Input under range
E - followed by
numerical
code
Controller error
Turn the furnace or oven off and back on to see if
this clears the error. If not contact Carbolite
Engineering Services – (see back cover)
13 Glossary of Terms
Process Value (PV) The actual temperature of the furnace or oven. °C
Setpoint (SP)
The target temperature the furnace or oven is trying to
reach.
°C
Setpoint Ramp Rate
The speed at which the furnace or oven is allowed to heat
up or cool down.
°C/Min
Element The heating device used in the furnace or oven. -
Thermocouple
The temperature measuring device used in the furnace or
oven.
-
PID
Proportional Integral Derivative: the control system used
by the controller.
-
Overtemperature (O/T)
The condition which a furnace or oven may enter if part of
the main control circuit fails.
-
Overtemperature
Protection
A system to prevent the product or process being
damaged if it has gone into an overtemperature condition.
-
Furnace or Oven This refers to the product purchased from Carbolite. -
