Zoom Mobility Scooter - MS01010014
13
5. Push the Seat Rotate Lever whilst pulling up on the seat to remove.
1. Make sure the tiller is raised before reassembling the scooter.
Please follow the steps:
6. Unlock the battery lock part and rotate the battery lock part.
2. Turn key switch to ‘OFF’.
7. Pick up the battery pack and remove it from the scooter.
3. Place the freewheel mode lever in the drive position.
8. Loosen the tiller adjustment knob and fold down the tiller and retighten knob.
4. Take off the basket.
9. Lock the front wheel and tiller by turning and pulling the wheel lock catch down.
10. Pull the connecting device upward to the rear section and stand upright.
11. Take off the front section with both hands and lower the shaft.
