CareCo MS01102 - Parts Description

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
8
3. Parts information
3.1 Parts description
1. Power Switch
2. Charger Socket Cover
3. Basket Bracket
4. Tiller Adjust Lever
5. Wheel Lock Knob
6. Seat Rotate Lever
7. Armrest
8. Width Adjustable Armrests Knob
9. Circuit Breaker
10. Freewheel Lever
11. Anti-tip Wheel
12. Connecting device
