Carel ?C2SE

68
A
D
BE
C
8 e 12 A
4A
A
D
BE
C
64
74.5
90
1950
84
15
29.535.519
12.53
74.5 12.53
Ø4
ENGLISH
µC
2
SE - +030220426 - rel. 2.1 - 09.06.2010
Model A (component
side)
B C D E
MCHRTF04C0 43 100 40 50 107
MCHRTF08C0 75 100 58 82 107
MCHRTF12C0 75 100 58 82 107
Note: the version with screw teminals code MCHRTF*D0 is available on request
Table 8.a
MCHRTF series single-phase speed controllers
Fig. 8.e
Fig. 8.f
Model
MCHRTF10C0
Table 8.b
