Carel EVD evolution User Manual

36
ENG
“EVD evolution” +030222041 - rel. 1.0 - 01.06.2008
Description Default Min Max Type CAREL SVP Modbus® R/W
ALARMS
Low suction temperature 0 0 1 D 1 0 R
LAN error 0 0 1 D 2 1 R
EEPROM damaged 0 0 1 D 3 2 R
Sensor S1 0 0 1 D 4 3 R
Sensor S2 0 0 1 D 5 4 R
Sensor S3 0 0 1 D 6 5 R
Sensor S4 0 0 1 D 7 6 R
EEV motor error 0 0 1 D 8 7 R
Relay status 0 0 1 D 9 8 R
ALARMS
LOP (low evaporation temperature) 0 0 1 D 10 9 R
MOP (high evaporation temperature) 0 0 1 D 11 10 R
LowSH (low superheat) 0 0 1 D 12 11 R
HiTcond (high condensing temperature ) 0 0 1 D 13 12 R
Status of digital input DI1 0 0 1 D 14 13 R
Status of digital input DI2 0 0 1 D 15 14 R
Enable EVD control 0 0 1 D 22 21 R/W
Tab. 8.c
Type of variable:
A= analogue,
D= digital,
I= integer
SVP= variable address with CAREL protocol on 485 serial card.
Modbus®: variable address with Modbus® protocol on 485 serial card.
