mpxone +0300086EN rel. 2.2 - 13.11.2023
Commissioning
P1: Type of electronic expansion valve
Code Description Def Min Max UOM User User terminal
P1 Electronic valve type
0 = not used/thermostatic valve
1 = CAREL unipolar E2V (MPXone Advanced)
2 = CAREL E2V driver and valve (superheat probes connected to the controller)
3, 4, 5 = reserved
6 = CAREL E2V driver and valve (superheat probes connected to the driver)
7 = PWM valve (0-10 V)
101- S YES
(*): for MPXone Advanced the default value is P1=1.
Notice: Using PWM valves requires a solid state relay (SSR) between the controller and the valve.
PH: Type of refrigerant
The type of refrigerant is essential for calculating the superheat value. In addition, it is used to calculate the evaporation and
condensing temperature based on the pressure probe reading. The table of predefined refrigerants is shown below.
Code Description Def Min Max UOM User User terminal
PH Refrigerant
Val. Desc. Val. Desc. Val. Desc.
0 N.A. 16 R413A 32 R447A
1 R22 17 R422A 33 R448A
2 R134a 18 R423A 34 R449A
3 R404A 19 R407A 35 R450A
4 R407C 20 R427A 36 R452A
5 R410A 21 R245Fa 37 R508B
6 R507A 22 R407F 38 R452B
7 R290 23 R32 39 R513A
8 R600 24 HTR01 40 R454B
9 R600a 25 HTR02 41 R458A
10 R717 26 R23 42 R407H
11 R744 27 HFO1234yf 43 R454A
12 R728 28 HFO1234ze 44 R454C
13 R1270 29 R455A 45 R470A
14 R417A 30 R170 46 R515B
15 R422D 31 R442A 47 R466A
3047- S YES
/P2: Type of probe, group 2 (S4, S5)
This is used to select the type of temperature probe to be used for inputs S4 and S5.
Code Description Def Min Max UOM User User terminal
/P2 Type of probe, group 2 (S4, S5)
1 = NTC Standard Range –50T90°C 2 = 0-5 V
3 = 4-20 mA
4 = Reserved
5 = Reserved
6 = 0.5 V-4.5 V (CAREL standard ratiometric)
606- S YES
/P3: Type of probe, group 3 (S6)
This is used to assign the type of probe connected to input S6.
Code Description Def Min Max UOM User User terminal
/P3 Type of probe, group 3 (S6)
0 = PT1000 Standard Range –50T150 °C
1 = NTC Standard Range –50T90°C 2 = 0-5 V
3 = 4-20mA
4 = 0-10V
5 = NTC-HT
6 = 0.5 V-4.5 V (CAREL standard ratiometric)
106- S YES
/P4: Type of probe, group 4 (S7)
This is used to assign the type of probe connected to input S8.
Code Description Def Min Max UOM User User terminal
/P4 Type of probe, group 5 (S8)
1 = NTC Standard Range –50T90°C
2 = 0-5 V
3,4,5 = Reserved
6 = 0.5 V-4.5 V (CAREL standard ratiometric)
616- S YES
