Carel pCO2 User Manual

2.1 Codici degli strumenti ed accessori
pCO
2
versione interfaccia e controllo
a 1+1 MB di memoria Flash codice
LARGE PCO2000AL0
MEDIUM PCO2000AM0
SMALL PCO2000AS0
LARGE - terminale built-in PCO2000BL0
MEDIUM - terminale built-in PCO2000BM0
SMALL - terminale built-in PCO2000BS0
LARGE - tre SSR (uscite 7, 12 e 14) PCO2003AL0
MEDIUM - due SSR (uscite 7 e 12) PCO2002AM0
SMALL - un SSR (uscita 7) PCO2001AS0
LARGE - terminale built-in, tre SSR (uscite 7, 12 e 14) PCO2003BL0
MEDIUM - terminale built-in, due SSR (uscite 7 e 12) PCO2002MB0
SMALL - terminale built-in, un SSR (uscita 7) PCO2001BS0
Versione a 2+2 MB di memoria Flash + EEPROM codice
LARGE PCO2000CL0
MEDIUM PCO2000CM0
SMALL PCO2000CS0
LARGE - terminale built-in PCO2000DL0
MEDIUM - terminale built-in PCO2000DM0
SMALL - terminale built-in PCO2000DS0
Tab. 2.1.1
Kit connettori estraibili
a vite codice
per pCO
2
SMALL PCO2CON0S0
per pCO
2
MEDIUM PCO2CON0M0
per pCO
2
LARGE PCO2CON0L0
a taglio di isolante codice
per pCO
2
SMALL PCO2CON2S0
per pCO
2
MEDIUM PCO2CON2M0
per pCO
2
LARGE PCO2CON2L0
a molla codice
per pCO
2
SMALL PCO2CON1S0
per pCO
2
MEDIUM PCO2CON1M0
per pCO
2
LARGE PCO2CON1L0
a crimpare codice
per pCO
2
SMALL PCO2CON3S0
per pCO
2
MEDIUM PCO2CON3M0
per pCO
2
LARGE PCO2CON3L0
Tab. 2.1.2
pCO
2
terminale utente
contenitore plastico per montaggio a pannello codice
display grafico 240x128 pixel, retroilluminato PCOI00PGL0
display LCD 4x20 retroilluminato PCOI000CBB
display LCD 4x20 PCOI000CB0
contenitore plastico per montaggio a pannello codice
e a parete
display grafico 64x128 pixel, retroilluminato PCOT00PGH0
display LCD 4x20 PCOT000CB0
display LCD 4x20 con predisposizione
collegamento stampante PCOT00SCB0
display LCD 4x20 retroilluminato PCOT000CBB
display LED 6 digit PCOT000L60
contenitore plastico per montaggio a codice
pannello 32X72
display LED 3 digit PCOT32RN00
Tab. 2.1.3
2.1 Instrument and accessory codes
pCO
2
interface and control version
with 1+1 MB Flash memory code
LARGE PCO2000AL0
MEDIUM PCO2000AM0
SMALL PCO2000AS0
LARGE - built-in terminal PCO2000BL0
MEDIUM - built-in terminal PCO2000BM0
SMALL - built-in terminal PCO2000BS0
LARGE - Three SSR (outputs no.7, 12 and 14) PCO2001AL0
MEDIUM - two SSR (outputs no.7 and 12) PCO2001AM0
SMALL - one SSR (output no.7) PCO2001AS0
LARGE - built-in terminal, three SSR (outputs no.7,
12 and 14) PCO2003BL0
MEDIUM - built-in terminal, two SSR (outputs no.7
and 12) PCO2002MB0
SMALL - built-in terminal PCO2001BS0
Version with 2+2 MB Flash memory + EEPROM code
LARGE PCO2000CL0
MEDIUM PCO2000CM0
SMALL PCO2000CS0
LARGE - built-in terminal PCO2000DL0
MEDIUM - built-in terminal PCO2000DM0
SMALL - built-in terminal PCO2000DS0
Tab. 2.1.1
Removable connector kits
screw code
for pCO
2
SMALL PCO2CON0S0
for pCO
2
MEDIUM PCO2CON0M0
for pCO
2
LARGE PCO2CON0L0
IDC (insulator displacement connector) code
for pCO
2
SMALL PCO2CON2S0
for pCO
2
MEDIUM PCO2CON2M0
for pCO
2
LARGE PCO2CON2L0
spring code
for pCO
2
SMALL PCO2CON1S0
for pCO
2
MEDIUM PCO2CON1M0
for pCO
2
LARGE PCO2CON1L0
pitch header code
for pCO
2
SMALL PCO2CON3S0
for pCO
2
MEDIUM PCO2CON3M0
for pCO
2
LARGE PCO2CON3L0
Tab. 2.1.2
pCO
2
user terminal
plastic case for panel mounting code
graphic display 240x128 pixel, back-lit PCOI00PGL0
LCD display 4x20 back-lit PCOI000CBB
LCD display 4x20 PCOI000CB0
plastic case for panel mounting and
wall-mounting code
graphic display 64x128 pixel, back-lit PCOT00PGH0
LCD display 4x20 PCOT000CB0
LCD display 4x20 ready for printer connection PCOT00SCB0
LCD display 4x20 back-lit PCOT000CBB
6 digit LED display PCOT000L60
plastic case for panel mounting 32X72 code
3 digit LED display PCOT32RN00
Tab. 2.1.3
11
pCO
2
- cod. +030221835 rel. 3.0 - 18.02.03
