Carel pCO3 series User Manual

pCO Sistema
Code: +030220336 - rel. 1.5 - 22/12/10
10
Connector
ConnectorConnector
Connector Signal
Signal Signal
Signal Description
DescriptionDescription
Description
J14-2 NO7 normally open contact, relay no. 7
J14-3 C7 common for relay no. 7
J15-1 NO8 normally open contact, relay no. 8
J15-2 C8 common for relay no. 8
J15-3 NC8 normally closed contact, relay no. 8
J16-1 C9 common for relays: 9, 10, 11
J16-2 NO9 normally open contact, relay no. 9
J16-3 NO10 normally open contact, relay no. 10
J16-4 NO11 normally open contact, relay no. 11
J16-5 C9 common for relays: 9, 10, 11
J17-1 NO12 normally open contact, relay no. 12
J17-2 C12 common for relay no. 12
J17-3 NC12 normally closed contact, relay no. 12
J18-1 NO13 normally open contact, relay no. 13
J18-2 C13 common for relay no. 13
J18-3 NC13 normally closed contact, relay no. 13
J19-1 ID15H digital input 15, 230 Vac
J19-2 ID15 digital input 15, 24 Vac/Vdc
J19-3 IDC15 common for digital inputs 15 and 16 (negative pole for DC power supply)
J19-4 ID16 digital input 16, 24 Vac/Vdc
J19-5 ID16H digital input 16, 230 Vac
J20-1 Y5 analogue output no. 5 to 0 to 10 V
J20-2 Y6 analogue output no. 6 to 0 to 10 V
J20-3 B9 passive analogue input 9 (NTC, PT1000, ON/OFF)
J20-4 BC9 common for analogue input 9
J20-5 B10 passive analogue input 10 (NTC, PT1000, ON/OFF)
J20-6 BC10 common for analogue input 10
J20-7 ID17 digital input no. 17, 24 Vac/Vdc
J20-8 ID18 digital input no. 18, 24 Vac/Vdc
J20-9 IDC17 common for digital inputs 17 and 18 (negative pole for DC power supply)
J21-1 NO14 normally open contact, relay no. 14
J21-2 C14 common for relay no. 14
J21-3 NC14 normally closed contact, relay no. 14
J21-4 NO15 normally open contact, relay no. 15
J21-5 C15 common for relay no. 15
J21-6 NC15 normally closed contact, relay no. 15
J22-1 C16 common for relays: 16, 17, 18
J22-2 NO16 normally open contact no. 16
J22-3 NO17 normally open contact no. 17
J22-4 NO18 normally open contact no. 18
J22-5 C16 common for relays: 16, 17, 18
J23-1 E- E- terminal for RS485 connection to the I/O expansion modules
J23-2 E+ E+ terminal for RS485 connection to the I/O expansion modules
J23-3 GND GND terminal for RS485 connection to the I/O expansion modules
J24-1 +V term additional power supply terminal for Aria
J24-2 GND power supply common
J24-3 +5 Vref power supply for 0/5 V ratiometric probes
Note:
Note: Note:
Note: J19, J20, J21, J22 and J23 correspond to the “LARGE” model.
