Carel pCO3 series User Manual

pCO Sistema
Code: +030220336 - rel. 1.5 - 22/12/10
60
pCO
pCOpCO
pCO
XS
XSXS
XS
230/24 Vac
M
OUT
+V
analog output 1 (0/10 Vdc) analog output 2 (0/10 Vdc)
analog output 3 (PWM taglio di fase/ phase cutting)
L
N
digital input 1 digital input 2 digital input 3 digital input 4 digital input 5 digital input 6
digital output 1 digital output 2 digital output 3 digital output 4 digital output 5
probe 3 (0/5 V )
p
robe 4 (Carel NTC)
probe 2 (4/20 mA)
probe 1
(0/1 Vdc o 4/20 m A )
G
G0
SYNC
B1 B2 B3 B4
GND
+5VREF
+24VDC
Y1 Y2 Y3
GND
ID1 ID2 ID3 ID4 ID5 ID6
IDC1
RXTX- RXTX+ GND TLAN GND C1 NO1 NO2 NO3 C4 NO4 NO5 C5 NC5
J1
J5
J6
J7
J8 J9
J10 J11
J2 J3
J4
CLOCK CARD
SERIAL CARD
built-in terminal
xs
Fig. 8.c
Fig. 8.cFig. 8.c
Fig. 8.c

Carel pCO3 series Specifications

General

Protection Rating	IP20
Communication Ports	RS-485
Display	Graphic LCD with backlight
Power Supply	24 Vac/dc ±10%
Storage Temperature	+70°C
Humidity	10% to 90% non-condensing
