6
“Power+” +0500120IE - rel 1.1 - 02.05.2017
ENG
2. INTRODUCTION
Power+ is a drive designed to control compressors with sensorless-brushless permanent magnet motors (BLDC/BLAC)
or asynchronous induction motors. It is tted for panel installation or with heat sink outside of the panel. Conguration
and programming, as well as the run/stop controls and speed reference, are managed by a CAREL pCO controller or any
controller device via RS485 serial connection using the Modbus® protocol in master mode.
2.1 Functions and main features
In summary:
• compact dimensions for assembly in electrical panels;
• operation at ambient temperatures from -20 to 60°C;
• can be installed in residential and industrial environments;
• connection via serial network to Master programmable controller;
• network address can be congured by setting the dipswitches inside to the drive;
• can control various types of compressors;
• DCbus output power supply for external auxiliary devices;
• class B (in accordance with EN/UL 60730) and class R.1 (in accordance with EN/UL 60335-1) software for machine
safety management;
• integrated motor protection (only for models which specify it);
• STO (Safe Torque O ) safety digital input for system protection;
• panel installation or with heat sink outside of the panel, to optimise the dissipation of heat inside the electrical
panel;
• programmable acceleration curve to adapt to the required specications when starting compressor;
• high switching frequency to limit motor noise;
• detailed information on drive status via numerous read-only variables;
• protection functions for the drive (short-circuit, overcurrent, earth fault, overvoltage and undervoltage on the bus,
overtemperature, overload), motor/compressor (overload and limitation of current delivered, locked rotor) and
system (communication failure);
• Coldplate models to be thermal coupled to an auxiliary cooling device.
2.2 Models
Code Power supply
Nominal output
current (A)
Cooling type/ mounting
Frame size
(mm)
PS2**122B****
PS2**1220****
PS2**122A****
PS2**1221****
200 - 240Vac ± 10%, 1~ 12A
Without cooling adapter
Air forced heatsink
Coldplate
Finned heatsink
148x220x87
148x220x165
148x220x93
148x220x160
PS2**061B****
PS2**0610****
PS2**061A****
PS2**0611****
105-125Vac ± 10%, 1~ 6A
Without cooling adapter
Air forced heatsink
Coldplate
Finned heatsink
148x220x87
148x220x165
148x220x93
148x220x160
Tab. 2.a
For the dimensions see the related paragraphs “Dimensions”.
For Power+ Coldplate models see also the related paragraphs “Power+ Coldplate models”.
To see the full list of models refer to user manual cod. +0300093EN.
