Carel UE001 Addendum Manual

5
ENG
“UE BASIC” +0300043EN - rel. 1.0 - 02/12/09
Table of water circuit, electrical and electronic spare parts, UE001
to UE018
spare part code position  g.
UE001 UE003 UE005 UE008 UE009 UE010 UE015 UE018
Electrical and electronics
Power transformer: 460/24 V UEKTR30000 9 9.b
Tab. 9.a
(1) when ordering, as well as the controller code specify the complete
code and serial number of the humidi er.
(2) xx: kg/h ( 01,......65)
v: power supply
z: match digit board
i: 0 single package / 1 multiple package
(3) w: match digit terminal
Table of spare part codes, three-phase cylinders UE003 to UE018,
electrode and gasket kit
Model UE003 UE005 UE008 UE010 UE015 UE018
STANDARD
disposable
cylinders
460 VAC 3~, conductivity 350 to 750 μS/cm BL0T1D00H2 BL0T2D00H2 BL0T2D00H2 BL0T3D00H2 BL0T3D00H2 BL0T3D00H2
SPECIAL
disposable
cylinders
460 VAC 3~, conductivity 75 to 350 μS/cm BL0T1B00H2 BL0T2C00H2 BL0T2C00H2 BL0T3C00H2 BL0T3C00H2 BL0T3C00H2
460 VAC 3~, conductivity 750 to 1250 μS/cm BL0T1D00H2 BL0T2D00H2 BL0T2D00H2 BL0T3D00H2 BL0T3D00H2 BL0T3D00H2
SPECIAL
openable
cylinders
460 VAC 3~, conductivity 75 to 350 μS/cm BLCT1B00W2 BLCT2C00W2 BLCT2C00W2 BLCT3C00W2 BLCT3C00W2 BLCT3C00W2
460 VAC 3~, conductivity 350 to 750 μS/cm BLCT1D00W2 BLCT2D00W2 BLCT2D00W2 BLCT3D00W2 BLCT3D00W2 BLCT3D00W2
460 VAC 3~, conductivity 750 to 1250 μS/cm BLCT1D00W2 BLCT2D00W2 BLCT2D00W2 BLCT3D00W2 BLCT3D00W2 BLCT3D00W2
Electrode
and gasket
kit
Electrode kit 460 Vac 3~, 75/350 μS/cm KITBLCT1B2 KITBLCT2C2 KITBLCT2C2 KITBLCT3C2 KITBLCT3C2 KITBLCT3C2
Electrode kit 460 Vac 3~, 350/750 μS/cm KITBLCT1D2 KITBLCT2D2 KITBLCT2D2 KITBLCT3D2 KITBLCT3D2 KITBLCT3D2
Electrode kit 460 Vac 3~, 750/1250 μS/cm KITBLCT1D2 KITBLCT2D2 KITBLCT2D2 KITBLCT3D2 KITBLCT3D2 KITBLCT3D2
Filter gasket kit KITBLC1FG0 KITBLC2FG0 KITBLC2FG0 KITBLC3FG0 KITBLC3FG0 KITBLC3FG0
Tab. 11.c
description spare part code position  g.
UE025 UE035 UE045 UE065
Power transformer: 460 /4V UEKTR30000 11 9.d
F1 - F2 460 Vac power fuses URKFUSE100 -
see electrical draw
Tab. 9.d
(1) when ordering, as well as the controller code specify the complete code
and serial number of the humidi er.
(2) xx: kg/h ( 01,......65)
v: power supply
z: match digit board
i: 0 single package / 1 multiple package
(3) w: match digit terminal
Table of spare parts for standard and special cylinders UE025 to
UE065
Description UE025 UE035 UE045 UE065
460V 3ph cylinder, conductivity 350 to 1250 μS/cm BL0T4D00H2 BL0T4D00H2 BL0T4D00H2 BL0T5D00H0
SPECIAL disposable cylinders 460V 3ph cylinder, conductivity 75 to 350 μS/cm BL0T4D00H2 BL0T4C00H2 BL0T4C00H2 BL0T5C00H0
SPECIAL openable cylinders 460V 3ph cylinder, conductivity 75 to 350 μS/cm BLCT4D00W2 BLCT4C00W2 BLCT4C00W2 BLCT5C00W0
460V 3ph cylinder, conductivity 350 to 1250 μS/cm BLCT4D00W2 BLCT4D00W2 BLCT4D00W2 BLCT5C00W0
Electrode and gasket kit 460V 3ph cylinder, conductivity 75 to 350 μS/cm KITBLCT4D2 KITBLCT4C2 KITBLCT4C2 KITBLCT5C0
460V 3ph cylinder, conductivity 350 to 1250 μS/cm KITBLCT4D2 KITBLCT4D2 KITBLCT4D2 KITBLCT5D0
Gasket and  lter kit KITBLC4FG0 KITBLC4FG0 KITBLC4FG0 KITBLC5FG0
Tab. 9.e
