Display NO YES NO
Maximum quantity of coffee dispensed per hour 240 480 480
Width (mm.) 306 577 577
Height (mm.) 498 498 498
Depth (mm.) 476 476 476
Net weight (Kg.) 32 45 45
Boiler capacity (lt.) 4 10 10
Hot water nozzle 1 1 1
Steam nozzle 1 1 2
Automatic cappuccino LM maker optional 1 1 1+1
Boiler resistor (W) Standard version 1600 2700 2700
Voltage 230V mono.
200V mono.
120V mono.
230V mono.
200V mono.
230V mono.
200V mono.
Materials used:
• Copper for boiler and piping
• reinforced silicone for the articulated feed tube
• reinforced silicone for the articulated pump tube
• brass chromed for the brewing group
• brass for taps and connections
• Working area in stainless steel for Pratica, painted stainless for Pratica Double steam.
Peripheral applications: serial connection RS232C for I/O interface 18/26 relay
NOTE: The registration and technical data plate of the machine is on the side of the machine behind the drip tray.
