Carlisle Binks E2-15 - Fluid Section Faults

EN
d) Cam direction incorrect
c) Cam follower worn
b) Main shaft bearings worn
a) Ball checks not seating correctly.
a) Worn piston seals
a) Replace piston seals.
a) No power
b) Inverter Unit or safety interlocks
‘tripped’
b) Check inverter and fault
conditions
a) Check electrical supply
c) Inspect, clean and/or replace balls
and seats.
b) Replace piston seals.
a) Check o-rings and hose
connections
c) Ball checks not seating correctly.
b) Worn piston seals
a) Air entering the suction
hose/manifold
b) Inspect, clean and/or replace balls
and seats.
b) Inverter Unit or safety interlocks
‘tripped’
Pump will not run
Fault Finding
Fluid Section
Pump runs, but lack of pressure
Paint leaking from inside cover
Bellows seal failure
Replace bellows seal, check piston
seal, replace as necessary
Excessive Pressure Pulsation
Replace bellows seal, check piston
seal, replace as necessary
Pump will not ‘Prime’
Symptom
Possible Cause
Remedy
