Carlisle Binks E2-15 - Technical Specifications

0.75 kW 4Pole 1400 RPM
EExde llA T4
50mm [1.97 ins]
Nominal flow volume / cycle:
0.375 l [0.10 US gal]
Variator Oil :- (502912 - 1 Litre Bottle):
Santotrac 50 Traction Fluid - 0.5 Litre
Fluid Output @ 20 HZ [10 cycles/min]
Fluid Output @ 80 HZ [40 cycles/min]
Fluid inlet connection: A/ B
Nominal pump stroke:
Maximum fluid pressure:
20 bar [290 psi]
3.75 l/min [1.0 US gal/min]
15 l/min [4.0 US gal/min]
1'' Sanitary
Total Weight of Pump (inc electric motor)
92 kg [202 lbs]
Max. Inlet Pressure
2 bar [29 psi]
AC Induction Electric Motor- EU Model
400V 3PH 0.75 kW @ 50HZ
0.75 kW 4Pole 1400 RPM - Japan Model
Output Speed
8 - 43 RPM (EU Model/Japan Model)
8 - 48 RPM (USA Model)
EN
SPECIFICATION
Gearbox Oil: EU Model/Japan Model
Synthetic 220 (typically Agip Blasia S)
77-3311 R1.0 4/36 www.carlisleft.com
