Carlisle DeVilbiss DV1 - Functional Description and Specifications; Functional Description; Specifications

EN
GAUGE ONLY
72g
Die Cast Aluminium, Chrome Plated
40°C Nominal [104°F]
The gauge is either supplied as a retrofit kit to existing DV1 sprayguns, or factory installed.
The gauge is powered by a long life battery and has a life expectancy of 2 years under normal shift
working conditions (following a max. 2 year shelf life).
P1 = Max Static Air Input Pressure
Chrome Plated Brass & Anodised Aluminium
FUNCTIONAL DESCRIPTION
AIR INLET PRESSURES
HOUSING
Toughened Glass
81 x 49 x 42 [3.2 x 1.9 x 1.65]
DIMENSIONS
L x H x W mm [inches]
SPECIFICATIONS
WEIGHT
ENVIRONMENTAL
Max Ambient Operating Temperature
VALVE PARTS
7 bar [100 psi]
MATERIALS OF CONSTRUCTION
The DGIPRO-505 Digital Pressure Gauge is an intrinsically safe device, approved to ATEX regulations
2014/34/EU, protection level; II 2 G Ex ia IIC T4 Gb, suitable for use in zones 1 and 2.
WINDOW
SB-E-9-223 R1.0
