Carlisle DeVilbiss DV1 - Product Assembly and Components; Exploded View Diagram; Parts Identification List

EN
13
704429
TOOL KIT
1
1
1
8
VALVE BODY
1
1
1
704426
DIGITAL GAUGE ASSEMBLY
1
SPREADER VALVE PIN
1
11
-
SCREW
1
12
704417
AIRFLOW VALVE
EXPLODED VIEW
REF.
PART No.
DESCRIPTION
QTY.
7
-
15
-
TOOL
1
16
-
TOOL
1
PARTS LIST
2
-
GAUGE MODULE
1
3
1
9
704421
KNOB AND SCREW KIT
1
10
-
VALVE ADJUSTING KNOB
14
-
TOOL
704420
DIGITAL GAUGE SPREADER VALVE
1
4
-
AIR VALVE STEM
1
5
-
-
O RING
3
6
-
O RING
11mm HEX
9 Nm
[80 in-lbs]
T10 TORX
1 Nm
[10 in-lbs]
SB-E-9-223 R1.0
5/8
www.carlisleft.com
