With the hose connected, turn on the air supply.
The gauge will show a reading in 0.05 bar [0.7 psi] increments.
The gauge will start reading at 0.2 bar [2.9 psi].
Adjust the flow valve until the required pressure value is displayed.
The gauge can be cleaned in a gun wash machine whilst attached to the spray gun.
This gauge is suitable for use with both water-based and solvent based coating materials and cleaners.
Please consult your gun washing machine supplier to confirm the suitability of this device being used
in their equipment.
Turn spreader valve (10) anti-clockwise until fully wound out.
Open the air flow valve (12) by turning anti-clockwise and trigger the spraygun (air only).
Turn the air flow valve (12) at the bottom clockwise until fully wound in.
However, please consult the manufacturer of the gun wash machine to ascertain suitability
with this product.
SB-E-9-223 R1.0
7/8
