2.6 Unit Specifications
2.6.1 Compressor Reference Data
2.6.2 Refrigeration System Data
2.6.3 Electrical Data
a. Fan Motors
b. Standby Compressor Speed
1760 rpm - 60 hz
Model Series 150
Displacement 8.91 in
3
(147 cc)
No. Cylinders 6
Weight 9.68 lbs (4.4 kg)
Oil Charge 6oz (180 ml) - Road and Standby
Additional Oil Charge 4.23 oz (123 ml)
NOTE: Additional oil is only to be charged at installation
Approved oil POE - Mobil Arctic EAL 68 (Carrier Part Number 46-60002-02)
Defrost Timer Automatic triggering or at preset intervals: 0, auto, 1h, 2h, 3h, 4h, 5h, 6h
Defrost Termination
Thermostat (Standby
Only)
Opens at: 50 ± 5°F (27 ± 3°C); Closes at: 40 ± 5°F (22.2 ± 3°C)
High Pressure Switch
(HP1)
Cutout at: 465 ± 10 psig (32 Bar); Cut-in at: 360 ± 10 psig (25 Bar)
Condenser Pressure
Switch (HP2)
Cutout at: 245 ± 10 psig
1
(17 Bar); Cut-in at: 320 ± 10 psig (22 Bar)
Refrigerant Charge Refer to Table 2–1
Compressor Pressure
Regulating Valve (CPR)
30.5 ± 1 psig (2.1 Bar) @ 2400 rpm
Thermostat Expansion
Valve
Superheat at 32°F (0°C) Box, 14.5°F (8°C)
Superheat at 0°F (-20°C) Box, 7°F (4°C)
Low Pressure Switch
(LP)
Cutout at: 0 ± 6 psig (0 Bar); Cut-in at: 14.5 ± 3 psig (1 Bar)
Quench Valve Thermo-
stat (BPT)
Opens at: 220° ± 7°F (105° ± 4°C); Closes at: 248° ± 7°F (120° ± 4°C)
Evaporator Fan Motor (EFM) Condenser Fan Motor (CFM)
Bearing Lubrication Factory Lubricated Bearing Lubrication Factory Lubricated
Horse Power 100W 70W
Operating Amps 7-9 amps Operating Amps 7.5 amps
Speed 2100 rpm (rated) Speed 2350/2600 rpm
