19
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
To t a l Sens‡ Tota l Sens‡ To tal Sens‡ To t al Sens‡ To t al Sens‡ To t a l Sens‡
24ABA448A30 Outdoor Section With CAP**6024A** Indoor Section
1400
72 60.16 31.56 3.28 57.50 30.54 3.65 54.64 29.46 4.05 51.60 28.32 4.50 48.30 27.10 4.99 44.61 25.76 5.51
67 55.07 38.75 3.27 52.61 37.72 3.64 50.00 36.62 4.05 47.20 35.47 4.49 44.18 34.24 4.98 40.83 32.90 5.51
62 50.45 45.90 3.27 48.23 44.83 3.64 45.88 43.71 4.04 43.41 42.48 4.49 40.91 40.91 4.98 38.37 38.37 5.51
57 48.92 48.92 3.27 47.14 47.14 3.63 45.23 45.23 4.04 43.17 43.17 4.49 40.91 40.91 4.98 38.37 38.37 5.51
1600
72 61.17 33.06 3.37 58.39 32.02 3.73 55.41 30.92 4.14 52.25 29.77 4.58 48.82 28.53 5.07 45.00 27.17 5.59
67 56.03 41.17 3.36 53.46 40.12 3.72 50.73 39.00 4.13 47.83 37.84 4.57 44.70 36.59 5.06 41.24 35.22 5.59
62 51.54 49.21 3.35 49.27 48.08 3.72 46.90 46.90 4.12 44.73 44.73 4.57 42.31 42.31 5.06 39.58 39.58 5.59
57 50.90 50.90 3.35 48.99 48.99 3.72 46.94 46.94 4.12 44.73 44.73 4.57 42.31 42.31 5.06 39.58 39.58 5.59
1800
72 61.90 34.47 3.45 59.02 33.42 3.81 55.95 32.30 4.22 52.69 31.14 4.66 49.16 29.88 5.15 45.24 28.51 5.67
67 56.72 43.47 3.44 54.07 42.40 3.80 51.26 41.28 4.21 48.28 40.10 4.66 45.07 38.82 5.14 41.52 37.41 5.67
62 52.54 52.16 3.43 50.46 50.46 3.80 48.29 48.29 4.20 45.95 45.95 4.65 43.40 43.40 5.14 40.51 40.51 5.67
57 52.49 52.49 3.43 50.46 50.46 3.80 48.29 48.29 4.20 45.96 45.96 4.65 43.40 43.40 5.14 40.52 40.52 5.67
Multipliers for determining the performance with other indoor sections.
Cooling
Indoor Model
Capacity Power Furnace Model
*CAP**6024A** 1.00 1.00
CAP**4817A** 0.97 0.99
CAP**4821A** 0.99 1.02
CAP**4824A** 0.99 1.02
CAP**6021A** 0.98 0.98
CNPF*4818A** 0.97 0.99
CNPH*4821A** 0.99 1.02
CNPH*6024A** 1.00 1.00
CNPV*4821A** 0.99 1.02
CNPV*4824A** 0.99 1.02
CNPV*6024A** 1.00 1.00
CSPH*4812A* * 0.98 1.01
CSPH*6012A* * 0.99 0.99
FV4BNB006 1.01 0.93
FV4BNF005 1.00 0.92
FX4BNB060 1.01 1.04
FX4BNF048 1.00 1.03
FX4CN(B,F)048 1.01 0.97
FX4CN(B,F)060 1.03 0.95
FY4ANB060 1.01 1.01
FY4ANF048 0.99 1.02
CAP**4817A** 0.96 0.96 58CV(A,X)090---16
CNPH*4821A** 0.97 0.97 58CV(A,X)090---16
CNPH*6024A** 0.99 0.95 58CV(A,X)090---16
CSPH*4812A* * 0.98 0.98 58CV(A,X)090---16
CSPH*6012A* * 1.00 0.96 58CV(A,X)090---16
CAP**4821A** 0.97 0.97 58CV(A,X)110---20
CAP**6021A** 0.98 0.94 58CV(A,X)110---20
CNPV*4821A** 0.97 0.97 58CV(A,X)110 ---20
CAP**4824A** 0.98 0.94 58CV(A,X)135---22
CAP**6024A** 1.00 0.96 58CV(A,X)135---22
CNPV*4824A** 0.98 0.94 58CV(A,X)135 ---22
CNPV*6024A** 1.00 0.96 58CV(A,X)135 ---22
CAP**4824A** 0.98 0.94 58CV(A,X)155---22
CAP**6024A** 1.00 0.92 58CV(A,X)155---22
CNPV*4824A** 0.98 0.94 58CV(A,X)155 ---22
CNPV*6024A** 1.00 0.92 58CV(A,X)155 ---22
CAP**4821A** 0.97 0.97 58MVB080---20
CAP**6021A** 0.97 0.97 58MVB080---20
CNPH*4821A** 0.97 0.97 58MVB080 ---20
CNPH*6024A** 0.99 0.99 58MVB080 ---20
CNPV*4821A** 0.97 0.97 58MVB080---20
CSPH*4812A* * 0.98 0.98 58MVB080---20
CSPH*6012A* * 0.99 0.99 58MVB080---20
CAP**4821A** 0.97 0.97 58MVB100---20
CAP**6021A** 0.97 0.93 58MVB100---20
CNPV*4821A** 0.97 0.97 58MVB100---20
CAP**4824A** 0.97 0.97 58MVB120---20
CAP**6024A** 0.99 1.02 58MVB120---20
CNPV*4824A** 0.97 0.93 58MVB120---20
CNPV*6024A** 0.99 0.95 58MVB120---20
See notes on pg. 20
