COMBINATION RATINGS CONTINUED

ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER

3043547 24ABB360A31 CNPV*6024A** 58CV(A,X)155---22 56500 11.20 13.50

3099383 24ABB360A31 CNPV*6024A** 58MEB120---20 56500 11.00 13.20

3043531 24ABB360A31 CNPV*6024A** 58PH*135---20 56000 11.00 13.20

3043545 24ABB360A31 CNPV*6024A**+TDR 57000 11.00 13.00

3043552 24ABB360A31 CSPH*6012A** 58CV(A,X)110---20 56500 11.00 13.20

3043553 24ABB360A31 CSPH*6012A** 58CV(A,X)135---22 56500 11.20 13.50

3043554 24ABB360A31 CSPH*6012A** 58CV(A,X)155---22 56500 11.20 13.50

3099386 24ABB360A31 CSPH*6012A** 58MEB100---20 56500 11.00 13.20

3099387 24ABB360A31 CSPH*6012A** 58MEB120---20 56500 11.00 13.20

3043535 24ABB360A31 CSPH*6012A** 58PH*090---16 56000 11.00 13.20

3043536 24ABB360A31 CSPH*6012A** 58PH*110---20 56500 11.20 13.20

3043537 24ABB360A31 CSPH*6012A** 58PH*135---20 56000 11.00 13.20

3043551 24ABB360A31 CSPH*6012A**+TDR 57500 11.00 13.00

3069699 24ABB360A31 FE4ANB006+UI 57500 11.50 13.50

3043556 24ABB360A31 FV4BNB006 57000 11.20 13.50

3043555 24ABB360A31 FX4CN(B,F)060 58000 11.00 13.20

3043557 24ABB360A31 FY4ANB060 56500 11.00 13.00

* Tested combination

EER — Energy Efficiency Ratio

SEER — Seasonal Energy Efficiency Rati o

TDR — T i m e --- D e l a y R el a y

NOTES:

1. In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use either the accessory

Time---Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Carrier furnaces are equipped with TDR.

2. Ratings are net values reflecting the effects of c irculating fan motor heat. Supplemental electric heat is not included.

2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedu res for central air condi tioners. Ratings for other combinations are determined under DOE

computer simulation procedures.
