23
DETAI LED COOLING CAPACITIES#
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Tota l Sens‡ Tot a l Sens‡ To tal Sens‡ Tota l Sens‡ Tota l Sens‡ Tot al Sens‡
24ABB318A31 Outdoor Section With CAP**1814A** Indoor Section
525
72 (22.2) 20.79 10.51 1.27 19.89 10.18 1.42 18.93 9.83 1.58 17.94 9.47 1.77 16.87 9.09 1.97 15.67 8.67 2.20
67 (19.4) 19.09 12.93 1.27 18.24 12.58 1.42 17.33 12.21 1.59 16.39 11.84 1.77 15.37 11.44 1.98 14.26 11.01 2.20
63 (17.2)†† 17.84 12.55 1.27 17.02 12.19 1.42 16.15 11.82 1.59 15.24 11.43 1.78 14.26 11.02 1.98 13.22 10.58 2.20
62 (16.7) 17.53 15.32 1.27 16.74 14.95 1.42 15.91 14.57 1.59 15.04 14.16 1.78 14.17 14.17 1.98 13.33 13.33 2.20
57 (13.9) 17.00 17.00 1.27 16.36 16.36 1.42 15.67 15.67 1.59 14.95 14.95 1.78 14.18 14.18 1.98 13.33 13.33 2.20
600
72 (22.2) 21.12 11.01 1.29 20.19 10.67 1.44 19.19 10.32 1.61 18.18 9.96 1.80 17.07 9.57 2.00 15.84 9.15 2.22
67 (19.4) 19.42 13.74 1.29 18.54 13.39 1.45 17.60 13.02 1.61 16.63 12.65 1.80 15.59 12.24 2.00 14.44 11.80 2.23
63 (17.2)†† 18.17 13.32 1.30 17.32 12.96 1.45 16.43 12.58 1.62 15.49 12.19 1.80 14.48 11.77 2.01 13.40 11.33 2.23
62 (16.7) 17.93 16.44 1.30 17.12 16.06 1.45 16.30 16.21 1.62 15.53 15.53 1.80 14.71 14.71 2.01 13.81 13.81 2.23
57 (13.9) 17.70 17.70 1.30 17.02 17.02 1.45 16.29 16.29 1.62 15.53 15.53 1.80 14.71 14.71 2.01 13.81 13.81 2.23
675
72 (22.2) 21.35 11.48 1.32 20.39 11.14 1.47 19.37 10.79 1.64 18.34 10.43 1.83 17.20 10.04 2.03 15.94 9.61 2.25
67 (19.4) 19.66 14.52 1.32 18.76 14.17 1.47 17.79 13.80 1.64 16.81 13.42 1.83 15.74 13.01 2.03 14.58 12.56 2.25
63 (17.2)†† 18.41 14.06 1.32 17.55 13.70 1.48 16.63 13.31 1.64 15.67 12.92 1.83 14.64 12.49 2.03 13.54 12.03 2.26
62 (16.7) 18.28 18.11 1.32 17.55 17.55 1.48 16.79 16.79 1.64 15.99 15.99 1.83 15.13 15.13 2.03 14.18 14.18 2.25
57 (13.9) 18.26 18.26 1.32 17.55 17.55 1.48 16.79 16.79 1.64 15.99 15.99 1.83 15.13 15.13 2.03 14.18 14.18 2.25
COOLING INDOOR
MODEL
CAPACITY POWER FURN ACE MODEL
*CAP**1814A** 1.00 1.00
CAP**2414A** 1.02 1.01
CAP**2417A** 1.02 1.01
CNPF*2418A** 1.02 1.01
CNPH*2417A** 1.02 1.01
CNPV*1814A** 1.00 1.00
CNPV*2414A** 1.02 1.01
CNPV*2417A** 1.02 1.01
CSPH*2412A** 1.02 1.01
FE4ANF002 0.98 0.88
FF1ENP018 0.99 0.99
FF1ENP024 0.99 0.99
FV4BNF002 0.98 0.88
FX4CNF018 1.02 0.93
FX4CNF024 1.02 0.91
FY4ANF018 1.01 1.01
FY4ANF024 1.02 1.02
CAP**1814A** 0.99 0.90 58CV(A,X)070 ---12
CAP**2414A** 1.01 0.90 58CV(A,X)070 ---12
CNPH*2417A** 1.01 0.90 58CV(A,X)070--- 12
CNPV*1814A** 0.99 0.90 58CV(A,X)070--- 12
CNPV*2414A** 1.01 0.90 58CV(A,X)070--- 12
CSPH*2412A** 1.02 0.91 58CV(A,X)070--- 12
CAP**2417A** 1.01 0.90 58CV(A,X)090 ---16
CNPH*2417A** 1.01 0.90 58CV(A,X)090--- 16
CNPV*2417A** 1.01 0.90 58CV(A,X)090--- 16
CSPH*2412A** 1.02 0.91 58CV(A,X)090--- 16
CAP**2417A** 1.02 0.89 58MEB040--- 12
CNPH*2417A** 1.02 0.91 58MEB040--- 12
CNPV*2417A** 1.02 0.91 58MEB040--- 12
CSPH*2412A** 1.02 0.91 58MEB040--- 12
CAP**2417A** 1.02 0.89 58MEB060--- 12
CNPH*2417A** 1.02 0.91 58MEB060--- 12
CNPV*2417A** 1.02 0.91 58MEB060--- 12
COOLING INDOOR
MODEL
CAPACITY POWER FURN ACE MODEL
CSPH*2412A** 1.02 0.91 58MEB060--- 12
CAP**2417A** 1.01 0.90 58MV(B,C)060--- 14
CNPH*2417A** 1.01 0.90 58MV(B,C)060---14
CNPV*2417A** 1.01 0.90 58MV(B,C)060 ---14
CSPH*2412A** 1.02 0.91 58MV(B,C)060 ---14
CNPH*2417A** 1.01 0.90 58MV(B,C)080---14
CSPH*2412A** 1.02 0.91 58MV(B,C)080 ---14
CNPH*2417A** 1.01 0.90 58MVB040--- 14
CSPH*2412A** 1.01 0.90 58MVB040--- 14
CAP**1814A** 1.01 0.92 58PH*045--- 08
CAP**2414A** 1.02 0.91 58PH*045--- 08
CNPH*2417A** 1.01 0.90 58PH*045---08
CNPV*1814A** 1.01 0.92 58PH*045--- 08
CNPV*2414A** 1.02 0.91 58PH*045--- 08
CSPH*2412A** 1.02 0.91 58PH*045--- 08
See notes on page 26
24ABB3
